CONSTRUCTION DATA:
Conductor:
# of Conductors
8
AWG
23 AWG
Conductor Stranding
Solid
Copper Type
Bare Copper
Insulation:
Type
Polyolefin
Thickness
.010 in.
Color Code
BL, WH/BL, OR, WH/OR, GN, WH/GN, BN, WH/BN
Shield:
Shield Type
N/A
Drain Wire Type
N/A
Drain Wire AWG
N/A
Jacket:
Jacket Type
UV Resistant Polyethylene
Nominal Cable O.D.
0.251 in.
Colors
Black
APPLICATIONS:
Networking
Security
X-REFERENCE:
WPW
4246IO
Belden
2147A
TECHNICAL DATA:
Voltage Rating
300V
Operating Temperature
-20°C to 60°C
Flame Test
UL 1685
NEC Rating
CM-LS
RoHS Compliant
Yes
Max. Pull Tension
35 lbs
Max. Bend Radius
1.255 in.
Cable Weight
43 lbs
Nominal DCR
22 Ohms/1000ft
Nominal Cap. Between Conductors
14 pF/ft
Nominal Cap. Cond. To Shield
N/A
