CONSTRUCTION DATA:
Conductor:
# of Conductors
8
AWG
23 AWG
Conductor Stranding
Solid
Copper Type
Bare Copper
Insulation:
Type
Polyolefin
Thickness
.010 in.
Color Code
BL, WH/BL, OR, WH/OR, GN, WH/GN, BN, WH/BN
Shield:
Shield Type
Overall Aluminum Foil
Drain Wire Type
Tinned Copper
Drain Wire AWG
24 AWG
Jacket:
Jacket Type
PVC
Nominal Cable O.D.
0.265 in.
Colors
Black
APPLICATIONS:
Networking
Security
X-REFERENCE:
WPW
4346AF
Belden
10GXW52
TECHNICAL DATA:
Voltage Rating
300V
Operating Temperature
-20 to 60 C
Flame Test
UL 1666
NEC Rating
CMR
RoHS Compliant
Yes
Max. Pull Tension
25 lbs
Max. Bend Radius
1.325 in.
Cable Weight
37 lbs
Nominal DCR
24 Ohms/1000ft
Nominal Cap. Between Conductors
16 pF/ft
Nominal Cap. Cond. To Shield
N/A
