CONSTRUCTION DATA:
Conductor:
# of Conductors
8
AWG
23 AWG
Conductor Stranding
Solid
Copper Type
Bare Copper
Insulation:
Type
Flouropolymer
Thickness
.010 in.
Color Code
BL, WH/BL, OR, WH/OR, GN, WH/GN, BN, WH/BN
Shield:
Shield Type
N/A
Drain Wire Type
N/A
Drain Wire AWG
N/A
Jacket:
Jacket Type
Plenum PVC
Nominal Cable O.D.
0.250 in.
Colors
Black, Blue, Pink, Yellow
APPLICATIONS:
Networking
Security
X-REFERENCE:
WPW
254346A
Belden
254346A
TECHNICAL DATA:
Voltage Rating
300V
Operating Temperature
-20 to 60 C
Flame Test
NFPA 262
NEC Rating
CMP
RoHS Compliant
Yes
Max. Pull Tension
25 lbs
Max. Bend Radius
1.250 in.
Cable Weight
37 lbs
Nominal DCR
24 Ohms/1000ft
Nominal Cap. Between Conductors
13 pF/ft
Nominal Cap. Cond. To Shield
N/A
